Doublefacers
By using height-adjustable thermo bars, temperature control is easier.
Specifications
We have two models to cater to your web width and speed.
| Model | Doublefacer CDL2 |
Doublefacer CDL6 |
|---|---|---|
| Max. Production Speed | 300m/Min. | 350m/Min. |
| Max. Paper Width | 2,200mm | 2,500mm |
| Machine Dimension *1 (WidthxLength) | 4,375mm×17,786mm | 4,433mm×23,490mm |
| Number of Installations *2 | 198units（Up to Dec. 2005） | |
*1 In case of 2,000mmMax. Paper Machine
*2 Including of CDL1、CDL2、CDL6 and CDL9
Features
| The pressure on the web is equalized spacially. |  |
Sheet quality is maintained even with a worn belt. |
|---|---|---|
| Thermo bars can be adjusted even if the hot plates are deflected. | |
Because the web edges are not needlessly pressed, warping is less likely. |
| Heat conductivity is efficient because the Doublefacer belt is pressed | |
High speed double facing is possible even for heavy combinations and double walls. |
| Optional thermo weights can be installed in the cooling section | |
Will further suppress noise and flute crushing. |
Themo Bar Type and Weight Roll Type（Comparative Table）
Comparison Chart showing advantages of the thermo bar system over the conventional Weight Roller system
| Thermo Bar Type | Weight Roll Type （Convent.Type） | |
|---|---|---|
| Variation of Pressure on the web | GOOD: Variation among various web width. | Pressure varies among various web width |
| On Deflected Hotplates | GOOD: The Thermo Bars can conform to the deflection, so there is no crushing on the edges. | Web edges will get crushed on deflected hot plates. |
| Heat Conductivity Efficiency |
GOOD: Good heat transfer because the bars press by pads, not by rollers. | Heat transfer is not as good because the area of pressing is smaller. |
- On heavier webs, speed increases of 5 to 10 percent have been achieved.
- Easier to contain warping
- Noises have decreased by 5 to 10 dbs.
- Decreased need for steam shower.
- 50 percent less edge crush.
